24V Electronic Start 6LTAA8.9-G2 Cummins G Drive Engines For Generator Set , 220 KW / 1500 RPM
 |
Product Details:
| Place of Origin: | Xiangyang city, Hubei, China |
| Brand Name: | DCEC Cummins |
| Certification: | ISO/16949, ISO14001 |
| Model Number: | 6LTAA8.9-G2 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 set |
|---|---|
| Price: | Negotiation |
| Packaging Details: | Wooden box with plastic bag inside or Custimized as client's request |
| Delivery Time: | 3-7 working days on reciept of yr advance payment |
| Payment Terms: | L/C, T/T, Western Union |
| Supply Ability: | 200 units/per month |
Detailed Product Description
| Engine Model: | 6LTAA8.9-G2 | Usage: | Generator Set |
|---|---|---|---|
| Frequency: | 50Hz | Rated Power: | 220KW |
| Cylinders: | 6 | Strokes: | 4 |
| Payment: | TT Or LC | Cell/Wsapp Number: | +86+18827054157 |
24V Electronic Start 6LTAA8.9-G2 Cummins G Drive Engines For Generator Set , 220 KW / 1500 RPM
| Technical parameters of diesel generator sets: | ||||||||
| Generator Set | ||||||||
| Generator Model | KY200GF | |||||||
| Prime Power | 220kw | |||||||
| Rated Voltage | 400/230V | |||||||
| Frequency | 50Hz | |||||||
| Power Factor | 0.8(lagging) | |||||||
| Dimension (L×W×H) (mm) | 2600*950*1650 mm | |||||||
| Genset weight (kg) | 2100 kg | |||||||
| Diesel Engine | ||||||||
| Brand | Cummins | |||||||
| Type | 6LTAA8.9-G2 | |||||||
| Number of Cylinders | 6 | |||||||
| Rotating Speed | 1500RPM | |||||||
| Cycle | Four stroke | |||||||
| Cooling Method | Water Cooling | |||||||
| Bore×Stroke(mm) | 114*135 | |||||||
| Displacement(L) | 8.9 | |||||||
| Compression Ratio | 16.6:1 | |||||||
| Speed Governor | Electrical | |||||||
| Cooling System | Water-cooled | |||||||
| Total Lubrication System Capacity (L) | / | |||||||
| Fuel Consumption at 100% Load | 59 L/H | |||||||
| Starting Method | 24V Electrical starting | |||||||
The list of Genset Engine Models
| Mode | Rated Power(kw/rpm) | Brand |
| 4B3.9-G1 | 24/1500 | Cummins |
| 4B3.9-G2 | 24/1500 | Cummins |
| 4BT3.9-G1 | 36/1500 | Cummins |
| 4BT3.9-G2 | 36/1500 | Cummins |
| 4BTA3.9-G2 | 50/1500 | Cummins |
| 4BTA3.9-G2 | 58/1500 | Cummins |
| 4BTA3.9-G11 | 67/1500 | Cummins |
| 6BT5.9-G1 | 86/1500 | Cummins |
| 6BT5.9-G2 | 96/1500 | Cummins |
| 6BTA5.9-G2 | 106/1500 | Cummins |
| 6BTAA5.9-G2 | 120/1500 | Cummins |
| 6BTAA5.9-G12 | 132/1800 | Cummins |
| 6CTA8.3-G1 | 163/1500 | Cummins |
| 6CTA8.3-G2 | 170/1800 | Cummins |
| 6CTAA8.3-G2 | 183/1500 | Cummins |
| 6LTAA8.9-G2 | 220/1500 | Cummins |
| 6ZTAA13-G2 | 390/1800 | Cummins |
| 6ZTAA13-G3 | 340/1800 | Cummins |
| QSZ13-G2 | 500/1500 | Cummins |
A: Test before shippment
- Each Generator Set shall be put into commission more than 4 hours totally, tested on idle load, fully load and
10% overload.
- Noise level shall be tested.
- All of the meters on the control panel shall be tested.
- The appearance of the Set and the label, nameplate shall be tested. "
-Voltage available: 50Hz: 380-400-415V/ 220-230-240V; 60Hz: 220-380-416-440-480V/ 110-208-220-
240V. Any special voltage is also available as cilent's request.
B: Packing & Warranty
- Packing: Wooden Case, Plywood or Metal Case.
- Delivery Time: Less than 15 working days after receiving prepayment.
- Warranty: One year or 1, 000 hours from the date of shippment
(15 Months or 1, 200 hours for Alternator Part).
C: Payment
T/T, 30% deposit, 70% will be payed before delivery
T/T, 30% deposit , 70% L/C at sight
100% L/C at sight
D Assembly Process
