Xiangyang Xinsheng Power Technology Co.,Ltd.
Hope our service can make your working easy!
Place of Origin: | Xiangyang city, Hubei, China |
Brand Name: | Dongfeng Cummins |
Certification: | ISO/16949, ISO14001 |
Model Number: | 4BTAA3.9-C130 |
Minimum Order Quantity: | 1 SET |
---|---|
Price: | Negotiation |
Packaging Details: | Wooden box with plastic bag inside or Custimized as client's request |
Delivery Time: | 7 working days on reciept of yr advance payment |
Payment Terms: | L/C, T/T, Western Union |
Supply Ability: | 200 units/per month |
Engine Model: | 4BTAA3.9-C130 | Fule: | Diesel |
---|---|---|---|
Displacement: | 3.9L | Power: | 130HP |
Start: | Electronic Start | Brand: | Dongfeng Cummins |
After-sales Service Provided: | Overseas Service Center Available | Engine Condition: | New From Cummins Original Factory |
Suitable For: | Crane,loader,compressor,grader,roller,digger...... |
Cummins Engine 4BTAA3.9- C130 Use for Industry Construction Machines
Xiangyang Xinsheng Power Technology Co.,Ltd.
can supply cummins 4B3.9, 4BT3.9, 4BTA3.9 engine for oil drill equpments and other industry equipments.
Clean, efficient, dependable and durable, Cummins engines are found in nearly every type of vehicle and equipment on earth.
General Information of Cummins 4BTAA3.9-C130 Construction Diesel Engine
Engine Model :4BTAA3.9-C130
Engine Type :4 Cylinders, in Line
Displacement: 3.9 L
Bore*Stroke(mm) :102 * 120
Compression Ratio: 17.3 : 1
Net Weight (with flywleel & alternator) :338 Kg
Overall Diemension(L*W*H): 867mm*544mm*988mm
Technical Specification of Cummins 4BTAA3.9-C130 Construction Diesel Engine
Certification: Euro Ⅱ
Aspiration :Turbocharged-Intercooled
Fuel System :Direct Injection Pump
Electrical System(Starter Motor/Alternator): 12V/24V
Lowest Starting Temp without auxiliary system: -12℃
Cooling Method : Water Cooled
Performance Data of Cummins 4BTAA3.9-C130 Construction Diesel Engine
Rated Power : 97 kW/130 HP
Rated Speed :2200 rpm
Max.Torque/Speed :510 N.m @ 1400 rpm
Fuel Consumption: 210 g/Kw.h
Max. Continuous Running Altitude :2000 m
cummins diesel engine easy to repair, have service site all over the world, parts supply from
every local engine service site
Cummins Industrial Diesel Engine Model List:
Cummins Diesel Engine Model List | ||
Model | Rated power/Speed | PeakTorque/Speed |
(kW/rpm) | (N.m/rpm) | |
4BT3.9-C80 | 60/2200 | 330/1500 |
4BT3.9-C100 | 74/2400 | 330/1500 |
4BT3.9-C105 | 77/2800 | 330/1500 |
4BTA3.9-C80 | 82/2200 | 360/1400 |
4BTA3.9-C100 | 74/2200 | 410/1500 |
4BTA3.9-C110 | 82/2200 | 460/1500 |
4BTA3.9-C125 | 93/2200 | 475/1500 |
4BTA3.9-C130 | 97/2500 | 475/1500 |
6BT5.9-C130 | 97/2200 | 560/1500 |
6BT5.9-C150 | 112/2400 | 580/1500 |
6BTA5.9-C150 | 112/2200 | 670/1300 |
6BTA5.9-C170 | 125/2300 | 630/1400 |
6BTA5.9-C180 | 132/2200 | 750/1300 |
6CTA8.3-C195 | 145/1900 | 820/1500 |
6CTA8.3-C215 | 160/2200 | 908/1500 |
6CTA8.3-C230 | 172/2200 | 1003/1500 |
6CTA8.3-C240 | 179/2200 | 1028/1500 |
6CTA8.3-C260 | 194/2200 | 1135/1500 |
6LTAA8.9-C295 | 220/2100 | 1350/1400 |
6LTAA8.9-C300 | 225/2200 | 1268/1000 |
6LTAA8.9-C325 | 239/2200 | 1250/1500 |
6LTAA8.9-C340 | 250/2200 | 1380/1500 |
6LTAA8.9-C360 | 264/2200 | 1480/1500 |
After-sales service: Every Cummins engine is backed by Cummins Genuine Parts and Service, providing total customer support from over 5,500 worldwide locations every hour and every minute of every day.
Packaging & Delivery:
Packaging Detail:
Packaged By Exporting plywood case,woooden.
Delivery Detail:
Shipped in 7-10 working days after yr advance payment
We have Cummins engines for :
1) industry/construction equipments(excavator,crane,loader,drill,road roller,forklift,bulldozer,...),
2) boat,marine (marine propulsion power / marine generator set)
3) bus,coach, truck(dump truck,pickup truck,heavy truck,light truck,snow removal truck....)
4) generator set(hospital,factory,mine,oil field,data center,terminal,generating station....)
5) pumps(water pump,underwater pump,fire fighting pump, irrigation pump,sand pump....)
6) Explosion-proof cummins engines( the condition of flammable and explosive: coal mine,chemistry,medicament,paint,fireworks,petroleum..... )
(Suitable Cummins engines :4B, 6B, 6C, 6L, QS, ISF2.8,ISF3.8,,M11, N855, K19, K38, K50 series....)
